Cruizer

Cruizer 125-31

Long distance with onboard restroom

Onboard restroom FAST 6MT manual or ZF 6AT automatic Euro 6 engine

31
Seats: 430 Ps
Power: 7.6 m³
Hold

Request a quote Download datasheet (PDF)

Overview

Designed to travel

A 31-seat 2:1 configuration with an onboard restroom for the longest routes. 430 Ps Weichai Euro 6 engine with a choice of FAST 6MT manual or ZF 6AT automatic transmission, plus individual reading lights for every passenger.

Back to catalog

Onboard restroom

Enhances passenger experience on long-distance routes.

Transmission of choice

FAST 6MT manual (cost-efficient, robust) or ZF 6AT automatic (superior comfort).

Individual reading light

Positioned for each passenger for a comfortable experience.

Weichai Euro 6 · 430 Ps

430 Ps and 2,000 Nm with electric cooling fan.

Gallery

Cruizer 125-31

Specifications

Technical specs

Download datasheet (PDF)

Capacity & dimensions

Capacity: 31 seats (29 + driver + co-driver + restroom)
Seating layout: 2:1
Dimensions (L × W × H): 12,500 × 2,500 × 3,600 mm
Wheelbase: 6,300 mm
Gangway width: 400 mm
Empty weight: 12,365 kg
Gross weight: 15,820 kg
Luggage hold volume: 7.6 m³

Engine & transmission

Engine model: WP10.5H430E60
Type: Diesel, 6-cylinder in-line, turbocharged
Emission standard: Euro 6
Max. power: 430 Ps @ 1,900 rpm
Max. torque: 2,000 Nm @ 1,000–1,400 rpm
Transmission: FAST 6MT (6DSX200T) or ZF 6AT (6AP2020C)
Final ratio: 3.153 (MT) / 3.636 (AT)
Wheel rim (size / material): 9.00 × 22.5 steel / 8.25 × 22.5 aluminum
Tires: Maxxis / Michelin 12R22.5

Chassis & brakes

Front suspension: Dependent · 2 air bags · 2 shock absorbers · stabilizer bar
Rear suspension: Dependent · 4 air bags · 4 shock absorbers · stabilizer bar
Brakes (front / rear): Drum
Parking brake: Electromagnetic brake
Support system: ABS / ASR
Steering: Recirculating ball with hydraulic booster
