Linker T3
Linker T3-16
Top of the range: maximum payload
- 8.6 t
- Payload
- 160 Ps
- Power
- 7.0 m³
- Body
Overview
Designed to perform
The most capable Linker: 8.6 t payload, a ≈7.0 m³ body and 365 mm of clearance. 160 Ps, 480 Nm engine for the toughest jobs.
Back to catalogWeichai Euro 5 engine
Optimized power, exceptional durability and fuel efficiency.
Wanliyang transmission
8 forward and 2 reverse gears (high & low range), aluminum housing.
Hydraulic tipping ~55°
A-frame mechanism with chrome cylinder and large tipping angle.
Double-layer chassis
Longitudinal and cross members hot-pressed in one piece.
Well-equipped cabin
Dual-mode climate, power windows, 7" LCD cluster and 7" AVN display.
Electrostatic coating
Cargo body with full ED coating for maximum durability.
Gallery
Linker T3-16
Specifications
Technical specs
Weights
- Empty weight
- 6,325 kg
- Loading weight
- 8,600 kg
- Gross weight
- 15,120 kg
- Cabin capacity
- 3 seats
Dimensions
- Dimensions (L × W × H)
- 6,265 × 2,420 × 2,750 mm
- Cargo box (inner)
- 4,250 × 2,200 × 750 (≈7.0 m³)
- Wheelbase
- 3,600 mm
- Front / rear tread
- 1,800 / 1,733 mm
- Ground clearance
- 365 mm
Engine & transmission
- Engine model
- WP3NQ160E50
- Type
- Diesel, 4-cylinder in-line, turbocharged, direct injection with electronic control (ECU)
- Emission standard
- Euro 5
- Displacement
- 2,970 cc
- Max. power
- 160 Ps @ 3,000 rpm
- Max. torque
- 480 Nm @ 1,400–2,300 rpm
- Transmission
- WLY 6TS55 · 6 forward / 1 reverse
- Final ratio
- 6.73
- Tires
- 10.00-20
Chassis & steering
- Front suspension
- Dependent, leaf spring, hydraulic absorber
- Rear suspension
- Dependent, leaf spring
- Brakes (front / rear)
- Drum, hydraulic drive
- Steering
- Recirculating ball with hydraulic booster
Hydraulic system
- Hydraulic cylinder
- Ø160 × 685 mm
- Max. tipping angle
- 52°
- Fuel tank
- 200 L
- Battery
- 12V-100Ah × 2
Operation & cabin
- Max. speed
- 84 km/h
- Gradeability
- 49.6 %
- Turning radius
- 7.06 m
- Driver's seat
- Manual control
- Air conditioning
- Dual mode (heating & cooling)
- Charging ports
- USB Type A & Type C
- Driver's display
- 7" AVN screen · Bluetooth
Images and specifications are for reference only and may vary by version and market.
